Flat wire stator three-phase lead-in

Flat wire stator three-phase lead wires are a common motor stator design used to lead the output of three-phase AC power out. The following are details about flat wire stator three-phase lead wires:

1. Definition: Flat wire stator three-phase lead wires are the lead wires for the three windings (phases A, B, and C) on a motor stator, which usually consist of flat shaped wires. The windings of each phase consist of several coils, which are led through these flat wires and connected to the external circuit.
2. Structure and arrangement: The windings of a flat-wire stator generally consist of insulated wires (usually copper) which are arranged flat in the stator slots. The windings for each phase usually consist of a number of coils connected in series, the coils being separated from each other by insulating material. The lead wires extend from the stator slots for connection to external circuits.
3. Lead-in methods: The lead-in wires of a flat wire stator can be realized in various ways, depending on the design of the motor and the requirements of the application. Common lead-in methods include the following:

• Lead-in terminal boards: The lead-in wires for each phase are connected to external circuits by connecting them to the appropriate lead-in terminal boards. These terminal blocks are usually mounted on the end or side of the motor and provide convenient wiring points.
• Leadout Bundle: The leadout wires for each phase are led out by bundling them into a bundle for easy connection to external circuits. This approach provides a neat, compact wiring structure.
• Lead-in connector: The lead-in wires can be connected directly to external circuits through a connector, which can be a plug, socket or other connector.

1. Marking and Wiring: In order to properly connect and identify the lead wires of each phase, marking and wiring diagrams are usually used. The lead wires for each phase will be labeled A, B, and C, along with the corresponding polarity markings (usually numeric or color coded). The wiring diagram provides detailed connection information for the lead wires to ensure proper phase sequence and phase pairing.

Flat wire stator three-phase lead wires provide a convenient way to connect the motor’s three-phase outputs to external circuits. They are designed and arranged to meet the power requirements of the motor and provide easy wiring and maintenance. Proper connection and wiring of the lead wires is essential to ensure proper motor operation and phase sequence consistency.
