What is Hydrogen Oxygen Flame Motor Enameled Wire Welder
There are electric motors wherever electric current is needed to provide power, from the smallest hairdryer and electric toothbrush to the largest electric locomotive and so on.
Regardless of the type of electromagnetic wire used, the connections in the motor winding are always a critical factor in the quality of the motor. In comparison, the electromagnetic enameled wire winding can minimize the number of joints by continuous winding of the same phase winding, while the winding of other electromagnetic wires, whether high-voltage motors or low-voltage motors, whether the stator winding or rotor winding, there will be a lot of connections inside the winding, which is the key to test the motor production process.
Enameled wire welding machine principle
Enameled wire welding machine (also known as water welding machine) is to use water as fuel, through the electrochemical method of water electrolysis, producing hydrogen and oxygen, through the special hydrogen-oxygen flame gun ignition to form a hydrogen-oxygen flame, on the double-stranded or multi-stranded enameled wires are directly peeled and welded, without the need for additional peeling. As the temperature of the hydroxide flame is up to 2800 degrees, the joints of multi-strand enameled wires are directly welded into spherical shape under the action of the high-energy flame, and the welded joints are firm and reliable.
Advantages of enameled wire welding machine
Hydroxide flame enameled wire welding machine has the advantages of wide adaptability, long service life, no black smoke, reliable welding and so on, compared with the traditional touch welding and spot welding process.
Use of enameled wire welding machine
1.Installation
a) Equipped with the appropriate concentration of electrolyte, electrolyte cooling, through the host of the water port to join the machine.
b)Connect one end of the randomly configured hose to the air outlet of the host machine and the other to the hydrogen-oxygen flame gun.
c) Select a suitable flame nozzle from the gun box and connect it to the flame gun with a plate hand.
2.Power on
Turn on the power switch. The machine starts to produce gas when the pressure gauge indicates more than 0.1Mpa.
3.Welding
Aim the high-energy hydrogen-oxygen flame at the part where the enameled wire needs to be fused, and immediately fuse it into a ball shape.
- Flame out
Close the flame gun valve directly. Close the valve a little faster, not slowly.
- Shutdown
In the case of flameout turn off the machine host power switch, and then open the flame gun valve to release the excess gas in the machine.
Enameled wire welding machine classification
According to the welding of enameled wire wire diameter; enameled wire welding machine is divided into different models, different categories; different models of enameled wire welding machine, welding effect is different, enameled wire welding machine price difference.
