Rectifier transformers for electrolysis

A rectifier transformer for electrolysis is a special type of transformer used for DC power supply in electrolysis processes. It is mainly used in industrial electrolysis process to convert AC power supply to DC power supply suitable for electrolyzer.

Features:

1. high current output: the electrolysis process requires a high current supply, rectifier transformers for electrolysis are designed as special transformers capable of providing high current output.
2. Adjustable Output Voltage: During electrolysis, it is usually necessary to adjust the voltage of the electrolyzer, rectifier transformers for electrolysis can provide adjustable output DC voltage to meet the requirements of the process.
3. High efficiency and low loss: rectifier transformers for electrolysis are designed for high efficiency and low loss to minimize energy loss and heat generation.

Working Principle:

1. Input: The input of the rectifier transformer for electrolysis is connected to an AC power source, usually a three-phase AC source.
2. Transformer: The rectifier transformer has multiple windings, one of which is used to reduce the input voltage to the appropriate electrolyzer voltage.
3. Rectifier: The output winding of the transformer is connected to a rectifier, usually a rectifier bridge or electronic rectifier, which converts the AC power to DC power.
4. Output: The output of the rectifier is connected to the electrolyzer to supply DC power to meet the requirements of the electrolysis process.

The design and selection of rectifier transformers for electrolysis requires consideration of the following factors:

• Current and voltage requirements of the electrolyzer.
• Input power supply voltage and frequency.
• Efficiency requirements and energy loss limitations.
• Insulation class and safety requirements of the transformer.
