Polyesterimide Enameled Wire
Polyesterimide enameled wire, also known as PEI enameled wire, is an enameled wire with an insulation layer made of polyesterimide.
Tagged: transformer windings
What is the difference between hard copper core wire and soft copper core wire
Soft wire corrosion resistance is weaker, hard wire corrosion resistance is stronger; this is because the soft wire is a combination of multiple strands of fine copper wire, the total surface area of these copper wires must be much larger than a single strand of hard copper wire, and the larger the surface area, in contact with corrosive media, the rate of decay reaction is bound to be greater.
Copper stranded wire
Copper stranded wire is commonly used in electrical equipment, widely used in electrical installations, switchgear, electric furnaces and batteries, etc., to play the role of electrical conductivity and grounding, so the quality of copper stranded wire is very important. The purchase of copper stranded wire needs to start observing from the appearance, generally good copper stranded wire its appearance is relatively bright, service has obvious damage and scratches, there will be no obvious oxidation reaction generated by the discoloration phenomenon. The outer edge of the color is more uniform, service has black spots, service has cracks, the distance is uniform and regular. Meet the above criteria is a good choice of copper stranded wire.
Cable overhead steel strand
In order to protect the outer sheath of the cable from harm and reduce friction, the cable pulley is suspended on the steel strand. Its spacing is related to the weight of the cable unit length, generally installed every 2~3m distance, in order not to make the cable sag touch the ground as the principle, the cable pulley into a straight line installation. The wire mesh sheath is set at the end of the cable when used. When pulling the cable, the cable mesh sleeve and the wire rope must be installed between the anti-twist device.
High power transformer enameled wire varnish
High-power transformer wire enamel includes the following weight parts of raw materials: 50 parts of ethylene urea ethoxylate methacrylate, 28 parts of polyethylene glycol diacrylate, 8 parts of hydroxyethyl methacrylate, 4 parts of acid...
AC winding
The potential and magnetic potential generated by the AC winding and the final electromagnetic performance are only related to the connected conductors, but not to the order of connection. In other words, as long as the conductors are connected in the same slot, it does not matter which one is connected first and which one is connected second, the final reflected electromagnetic performance is basically the same, only the ends are different, there may be slightly different end leakage resistance and DC resistance.
Polyvinyl Chloride
Polyvinyl chloride (PVC) insulation is a common wire and cable insulation material with the advantages of low cost, good insulation performance, corrosion resistance, and easy processing. PVC insulation usually uses additives such as plasticizers...
Aluminum stranded wire with steel core
Aluminum stranded wire with steel core (ACSR) is an electric power transmission conductor, which is a reinforced wire with single or multiple layers of aluminum strands stranded outside a galvanized steel core. It is...
How to choose waterproof cable material
Cable waterproof way is generally divided into two kinds of longitudinal water resistance and radial diameter water. Longitudinal water resistance is generally used to block water yarn, water-blocking powder and water-blocking tape, their water-blocking mechanism is in these materials contain a water-expandable material, when the water from the end of the cable or from the sheath defects into the water, this material will be water quickly expand to prevent further diffusion of water along the cable longitudinal, so that the purpose of the cable longitudinal waterproofing. Radial water resistance is mainly achieved by extruding HDPE non-metallic sheathing or hot pressing, welding, cold drawing metal sheathing.
Communication Cable
Communication cable (English name: communication cable) is a cable used for near-range audio communication and long-range high-frequency carrier and digital communication and signal transmission, and is one of the five major cable products in...
